Steel Coil Rewinding Machine
| Model Number | FSHZ-00136 steel coil rewinding machine |
| Material Cutting | SS, HR, CR, GAL |
| Coil Weight | 5-15 Ton |
| Thickness | 0.3-3.0mm |
| Monthly Production | 6000-2000 Ton |
| Coil Width | 1300mm |
| Drive | AC |
Steel metal coil slitting machine, what’s the price of slitting line, Do you know more detail about automatic coil slitting and rewinding machine production line?
Coil Slitting machine can be categorized into thin strip slitting line and thick strip slitting line.
| Suitable materials are stainless steel(ss) | Aluminum coil and copper coil |
| Colored coil | Galvanized coil(GI) |
| Low carbon steel(CR) | Silicon steel |
|
Commodity |
2.0*650 |
2.0*1600 |
3.0*1250 |
9.0*1600 |
|
Raw material |
Carbon steel /stainless steel/ aluminum/copper/zinc/silver |
|||
|
Thickness |
0.2-2.0 |
0.2-2.0 |
0.3-2.75 |
2.0-9.0 |
|
Width |
150-650 |
500-1600 |
500-1250 |
800-1600 |
|
Inner diameter |
φ508/610 |
φ508/610 |
φ508/610 |
φ580/610/760 |
|
Outer diameter |
≤φ1500 |
≤φ1500 |
≤φ1500 |
≤φ2000 |
|
Coil Weight |
≤6 |
≤20 |
≤15 |
≤25 |
|
Width accuracy |
≤±0.05 |
≤±0.05 |
≤±0.05 |
≤±0.1 |
|
Slits |
≤16 |
≤32 |
≤12 |
≤12 |
|
Slits tolerance |
≥20 |
≥20 |
≥20 |
≥60 |
|
Speed |
≤180 |
≤200 |
≤180 |
≤40 |
|
Capacity |
-96 |
-240 |
-205 |
-265 |
|
Flood sapce |
11*4 |
22*7 |
22*6.5 |
28*10 |
Flow Chart of Slitting Lines:
Loading coils→decoiling→ pinching, leveling, and shearing→ looping→ guiding → slitting → rewinding scraps → looping → tension → recoiling → unloading baby coils → packing
a) Delivery time is 60-180 working days based on different machines
b) ODM 60-150 days after all info confirmed.
c) Depends on order quantity on hands
d) According to real production situation, appointment time of delivery.
